IMI ICO3S
Port size:1/4"...1/2" (ISO G / NPT) Namur or manifold
Direct acting solenoid valve
Reliable and long life, ideal for a one time installation
Safety Integrity Level SIL 2 / SIL 3 (redundant only)
Control of pneumatic or hydraulic operated equipment
Certifications:ATEX, CSA, TR CU, IECEx, FM, CSA, CRN, CCOE, IN-METRO, KOSHA, NEPSI, PESO (CCOE), Japan ISHL
Environmental protection: NEMA 4X, IP66/X8
產品應用
♦ Technical features
Medium:
Hydraulic and pneumatic - customer to specify and confirm compatibility
Operation:
Direct solenoid operated poppet valves
Mounting position:
Solenoid vertical
Flow:
0,6 Cv (8,7Kv) ... 1.7 Cv (24.5 Kv)
Port size:
G 1/4, 1/2 NPT, G 1/4, G 1/2 NAMUR or manifold versions
Operating pressure:
0... 12 bar(0…174 psi)
Temperature:
Media:-55…+90°C (-67... 194° F)
Ambient:See table on page 2
Air supply must be dry enough to avoid ice formation at emperatures below +2°C (+35° F).
Materials:
Valve body, trim, coil housing and top cover:stainless steel 1. 4404 (316 L)
O-rings seats & seals:NBR
Other seal materials available on request
